ASKAR 65PHQ, Telescópio APO Quintupleto Astrograph, 65mm, f/6.4
Askar 65PHQ Petzval Design
The Askar 65PHQ is a flatfield astrograph telescope designed for astrophotography out of the box. With its Petzval optical design, this telescope is fully corrected and provides a flat field capable of covering full frame sensors all without the need for an additional flattener. The Petzval design also allows you to connect a camera, filter wheel or filter drawer, and other accessories without having to worry about back focus.
Building on the success of the PHQ series, the 65PHQ is the smallest telescope in the line, which includes the 80PHQ, 107PHQ, 130PHQ, and 151PHQ models. All PHQ telescopes feature a Petzval design with two ED elements to eliminate chromatic aberration. Unlike other telescopes in the PHQ line, the 65PHQ uses a quintuplet (5-element) APO lens arrangement instead of the quadruplet design found on the other telescopes.
Askar 65PHQ Technical Specifications
- Aperture size: 65mm
- Focal length: 416mm
- Focal ratio: f/6.4
- Objective lens: Quintuplet air-spaced APO (including two ED glasses)
- Image circle: 44mm
- Maximum accessory connection (with the focuser fully retreated):
- 1. Imaging mode:
- 76mm (from the base of M48x0.75 male thread)
- 105mm (from the base of M54x0.75 male thread)
- 130mm (from the base of M68x1 male thread)
- 2. Observing mode:
- 121mm (from the end of 2" eyepiece holder)
- Total length:
- 328mm (including 1.25" eyepiece holder as dew shield contracted)
- 388mm (including 1.25" eyepiece holder as dew shield fully stretched)
- 360mm (including the 3-piece adapter as dew shield contracted)
- 420mm (including the 3-piece adapter as dew shield fully stretched)
- Net weight: 2kg
- Gross weight: 2.8kg
- Rear-end thread type:
- M68x1-M54x0.75
- M54x0.75-M54x0.75
- M54x0.75-M48x0.75 (M48x0.75 filter thread inside)
- Rear end of the 3-piece photographic adapters: M48x0.75
What's in the Box
- 65PHQ OTA
- Pair of tube rings
- Handle
- Askar 300mm Vixen dovetail plate
- A set of 3-piece photographic adapters
- Manual
Avaliações
Produto recebido em tempo compatível para uma entrega internacional, veio bem embalado e aparentemente tudo ok. De acordo com as primeiras impressões para ser um excelente tele. Obrigado
